- Details
-
- Commodity name: DFW low voltage cable branch box
DFW low-voltage cable branch box is made of stainless steel or composite materials through high-temperature molding. It has good impact resistance, bending strength, aging resistance, abrasion resistance, corrosion resistance, and easy installation. It can meet the needs of various harsh environments and places in outdoor engineering projects. It is suitable for power transmission and distribution in public places such as urban and rural power grid transformation, municipal engineering, residential areas and high-rise buildings, as a control and protection purpose.
Overview
DFW low-voltage cable branch box is made of stainless steel or composite materials through high-temperature molding. It has good impact resistance, bending strength, aging resistance, abrasion resistance, corrosion resistance, and easy installation. It can meet the needs of various harsh environments and places in outdoor engineering projects. It is suitable for power transmission and distribution in public places such as urban and rural power grid transformation, municipal engineering, residential areas and high-rise buildings, as a control and protection purpose.
Main technical parameters
Name High Width Depth DFW low voltage cable branch box 1000 600 350 DFW low voltage cable branch box (floor mounted) 1250 600 350 DFW low voltage cable branch box 1000 800 350 DFW low voltage cable branch box (floor mounted) 1250 1000 350 Note: The size can be determined according to user requirements
Conditions of use
• The ambient air temperature is not higher than 40°C and not lower than -5°C. The average temperature within 24 hours shall not be higher than +35°C;
• For indoor use, the altitude of the use location shall be ≤2000m;
• The relative temperature of the ambient air shall not exceed 50% at the highest temperature of +40°C; a higher relative humidity is allowed at lower temperatures, 90% at +20°C, and the influence of condensation that may be accidentally generated due to temperature changes should be considered; .
• If the user has special requirements, they can be negotiated with the manufacturer.Main features
• Fully insulated and fully sealed structure. Reliably ensure personal safety.
• Dustproof, fireproof, corrosion-resistant, maintenance-free, can be used outdoors or immersed in water, suitable for any harsh environment.
• The combination is extremely flexible and meets the requirements of various wiring.
• Small footprint, compact structure, simple installation and easy operation.Overall installation size mm
