ZGS-F/35kV Combined B Transformer for Wind Power Generation (American Type)
Photovoltaic New Energy Series
- Details
-
- Commodity name: ZGS-F/35kV Combined B Transformer for Wind Power Generation (American Type)
ZGS-F/35kV Combined Transformer for Wind Power Generation (American Style) (hereinafter referred to as Combined Transformer) is a special equipment that increases the 0.6-0.69kV voltage generated by wind turbines to 35KV and then connects to the grid for output.
ZGS-F/35kV Combined Transformer for Wind Power Generation (American Style) (hereinafter referred to as Combined Transformer) is a special equipment that increases the 0.6-0.69kV voltage generated by wind turbines to 35KV and then connects to the grid for output. Different from the traditional box-type substation, the high-voltage load switch, fuse and high-voltage components and the transformer body and the excitation tap-changer are sealed in two independent oil chambers respectively. The structure is compact and low-voltage power distribution can be configured as needed.
This product is used in various wind power generation sites and is the best supporting product for wind power generation systems.
Model meaning:
ZGS 口 - 口 F - 口 / 口 Combined transformer Performance level code High voltage wiring scheme Wind power generation Transformer rated capacity Voltage level Environmental conditions for use
• Cooling conditions: air self-cooling
• Environment for use:
• The outdoor ambient temperature is not higher than 40°C and not lower than -25°C, the altitude is not more than 1000m, the monthly average temperature is not more than 30°C, and the annual average temperature is not more than 20°C; at 25°C, the relative humidity of the air is not more than 95%, and the monthly average is not more than 90%;
• The horizontal acceleration is not more than 0.3g, and the vertical acceleration is not more than 0.15g;
• The installation environment should be free of obvious dirt, explosive, corrosive gases and dust, and the installation site should be free of severe vibration and shock. It is required to be installed on a cement platform or other flat and solid platform.
Note: Others exceeding the technical regulations shall be handled by the user and the company through consultation.Product Features
• Small size, compact structure, easy installation;
• Fully sealed, fully insulated structure, reliable guarantee of personal safety;
• Can be used in ring network and terminal, easy conversion;
• Low loss, low noise, superior performance;
• The box adopts anti-theft structure; .
• Low temperature rise and strong overload capacity.Main technical performance parameters:
Rated capacity
（KVA）
Rated capacity Connection resistance name No-load loss
（W）
Load loss
（W）
No-load cable
（%）
Short circuit impedance
（%）
High pressure（KV） Tap range Low pressure（KV） 630 35
38.5
±5%或
±2×2.5%
0.69 Dyn11 840 7820 0.9 6.5 800 1000 9350 0.8 900 1100 10450 0.8 1000 1250 11500 0.7 1250 1400 13850 0.6 1600 1700 1680 0.6
